| IRLP Computer Hardware Specification / All Models |
| CPU |
1 Ghz ULV Intel® Pentium® M/Celeron® M processor |
| System Memory |
512 Mbyte 1 x 200-pin DDR266 SODIMM |
| Chipset |
Intel® 852GM+ICH4 |
| BIOS |
Phoenix-Award 4Mbit with RPL/PXE LAN Boot ROM |
| SSD |
2 Gbyte CompactFlash™ type-II socket with DMA supported |
| Watchdog Timer |
Reset supported; 255 levels |
| Expansion Interface |
ECX expansion interface for DVO B/C, PCI and LPC |
| Battery |
Lithium 3V/196 mAH |
| Temperature |
0~60°C, operation |
| Operation Humidity |
10% ~ 95% relative humidity, non-condensing |
| MIO |
1 x PATA-100 IDE, 1 x FDD, 1 x PS/2 K/B + MS, 2 x COM (1 x RS-232, 1 x RS-232/422/485), 1 x LVDS
(optional), 1 x mini PCI, 2 x COM (RS-232) |
| Ethernet |
Onboard Realtek RTL8100C Fast Ethernet controller |
| Audio |
AC'97 codec audio |
| USB |
4 USB 2.0 ports via box-header for wiring solution |
| Digital I/O |
2 channel IN and 4 channel OUT |
| Video Chipset |
Integrated in Intel® 852GM GMCH |
| Video Memory Size |
up to 64MB frame buffer sharing system memory |
| Resolution CRT |
1920 x 1440@60Hz; LVDS LCD: 1400 x 1050@60Hz |
| Output Interface |
CRT connector for DAC output |
